Lathe Machine (C6236C) Center Dis.750mm, 1000mm, 1500mm
Product Features:
Hardened and ground bed ways.
Gears in headstock precisely ground to reduce noise.
Kinds of threads.
Electric system is reliable and safe.
Electromagnetic brake can be amounted when needed, and color at user option.
|
Specifications |
C6236C |
C6240C |
C6250C |
C6260C |
|||
|
Max. swing over bed |
360mm |
400mm |
500mm |
600mm |
|||
|
Max. swing over cross slide |
190mm |
230mm |
330mm |
430mm |
|||
|
Max. swing over gap |
520mm |
560mm |
660mm |
760mm |
|||
|
Center Distance |
750, 1000, 1500mm，2000mm ,3000mm |
||||||
|
Bed Width |
360mm |
||||||
|
Spindle hole |
52mm |
||||||
|
Spindle nose |
C6 |
||||||
|
Spindle taper |
MT6 |
||||||
|
Spindle speed(Number) |
(9steps)40-1400rpm 1600rpm |
||||||
|
Metric threads range |
18kinds 0.25-14mm |
||||||
|
Inch threads range |
27kinds 2-40inch |
||||||
|
Moudle threads range |
11kinds 0.5-3.5mπ |
||||||
|
Max. travel of top slide |
95mm |
||||||
|
Max. travel of cross slide |
180mm |
222mm |
|||||
|
Max. size of toolshank |
20*20mm 2 |
||||||
|
Dia. of tailstock sleeve |
65mm |
||||||
|
Taper of tailstock sleeve |
MT4 |
||||||
|
Max. travel of tailstock |
140mm |
||||||
|
Main drive motor |
4 or 5.5KW |
||||||
|
Coolant pump motor |
125W |
||||||
|
Packing size (L*W*H) |
|
||||||
|
750mm |
222*115*159cm |
||||||
|
1000mm |
247*115*159cm |
||||||
|
1500mm |
297*115*159cm |
||||||
|
2000mm |
347*115*159cm |
||||||
|
Net weight/Gross weight(kg) |
|
||||||
|
750mm |
1350/2000kg |
1400/2050kg |
1500/2150kg |
1600/2250kg |
|||
|
1000mm |
1450/2100kg |
1500/2150kg |
1600/2250kg |
1700/2350kg |
|||
|
1500mm |
1600/2250kg |
1650/2300kg |
1750/2400kg |
1850/2500kg |
|||
|
2000mm |
1800/2450kg |
1850/2500kg |
1950/2600kg |
2050/2650kg |
|||
|
Standard accessories |
Optional accessories |
|
3-jaw chuck |
Live center |
|
Center$center sleever |
Quick change tool post |
|
Wrenched |
Taper copy ruler |
|
Oil gun |
4-position longitudinal touch stop |
|
Operation manual |
|
|
Steady rest |
|
|
follow rest |
|
