Model Parameter |
DZG-2 | DZG-5 | DZG-10 | DZG-20 | DZG-40 | DZG-60 | DZG-80 | DZG-100 | |
| Unit Loading (T) | 2 | 5 | 10 | 20 | 40 | 60 | 80 | 100 | |
| Min diameter (mm) | Φ150 | φ250 | φ320 | φ500 | φ600 | φ750 | φ850 | φ1000 | |
| Max diameter(mm) | Φ1800 | φ2300 | φ2800 | φ3500 | φ4200 | φ4800 | φ5000 | φ5500 | |
| Rubber wheel diameter (mm) | φ200 | φ250 | 300 | 350 | 400 | 450 | 500 | 500 | |
| Rubber wheel thickness (mm) | 80 | 100 | 120 | 120 | 120 | 120 | 120 | 120 | |
| Metallic wheel diameter (mm) | / | φ240 | φ290 | φ340 | φ390 | φ440 | φ490 | φ490 | |
| Metallic wheel thickness (mm) | / | 20 | 25 | 30 | 40 | 50 | 60 | 70 | |
| Linear speed (m/h) | 6-60 | ||||||||
| Motor power (kw) | 0.18 | 0.75 | 1.1 | 1.5 | 3 | 4 | 4 | 5.5 | |
| Speed adjusting way | VFD | ||||||||
|
Model Parameter |
DZG-150 | DZG-200 | DZG-250 |
| Loading capacity(T) | 150T | 200T | 250T |
| Min suitable size of job (mm) | Φ1100 | Φ1500 | Φ1500 |
| Max suitable size of job(mm) | Φ6000 | Φ6000 | Φ6000 |
| Metallic wheel diameter (mm) | Φ500 | Φ550 | Φ550 |
| Metallic wheel thickness (mm) | 200 | 200 | 250 |
| Linear speed (m/h) | 6-60 | 6-60 | 6-60 |
| Motor power (kw) | 2×4 | 2×5.5 | 2×7.5 |
| Speed adjusting way | VFD | ||
