Technical Performance

※The upper roller can move vertically. The lower rollers can move horizontally. It has double functions of pre-bending and roll. And it can finish pre-bending and roll steel plate by feeding once.
※The three rollers are driving-roller. It can prevent skidding while rolling thin plates and enlarge the rolling scope.
※The three rollers have brake devices installed while revolving. It can make sure precise position and safe work while rolling.
※The upper roller can tilt to one side. And both ends of the upper roller can move up and down at the same time when it's tilted. It is benefit for rolling tapered workpiece.
※The main driver of the upper driver is supplied by multi-motor. It can reduce occupying area of the equipment because of compact structure.
※It's controlled by micro-machine and has digital display, simply operation and high efficiency.
※With reasonable structure and reliable working performance, it is fit for rolling medium and thick steel plates.
Technical Parameter

Spec	Max Width of Rolling Plate (mm)	Max Pre-bending Thickness (mm)	Max Width of Rolling Plate (mm)	Plate yield Limit (Mpa)	max spec. min bending diameter (mm)	Dia. Of Upper Roller (mm)	Dia. Of Lower Roller (mm)	Dia. Of Support Roller (mm)	center distance of lower roller (mm)	Rolling Speed (m/min)	Main Motor Power (kw)
W11XNC-60×2500	60	50	2500	245	1800	640	520		650	3.5	2×22
W11XNC-70×3200	70	60	3200	245	1800	720	600		900	3	2×30
W11XNC-70×4000	70	60	4000	245	2500	820	630		900	3	2×30
W11XNC-80×3000	80	70	3000	245	2000	770	600		900	3	2×30
W11XNC-100×3200	100	85	3200	245	2200	920	480	480	1000	3
W11XNC-120×4000	120	100	4000	245	4000	1020	550	550	1050	3	2×30
W11XNC-140×4000	140	120	4000	245	4000	1100	600	650	1200	3	4×45
W11XNC-160×4000	160	140	4000	245	4000	1280	650	650	1350	3	4×55
W11XNC-180×4000	180	160	4000	245	4000	1350	1100		1560	2.5	4×55
