2.A universal multi-purpose product with strong torque.
3.High stability & rigidity, easy operation.
4.XY axis auto power feed
5.Vertical milling head
| Specification | X6028 |
| Spindle taper | ISO40 7:24 |
|
Distance from spindle nose to worktable surface (mm) |
0-320 |
|
Distance from spindle center to vertical guide way surface (mm) |
280 |
| Spindle speed range (r.p.m) | 40-1300 (12 step) |
| Worktable size (mm) | 1200×280 |
| Worktable travel (X/Y/Z) (mm) | 700×300×350 |
| Main motor power (kw) | 2.2 |
| Overall dimension (mm) | 1400×1560×1700 |
| N.W/ G.W (kg) | 1300/1400 |
