1.Rectangular table guideways with high stability
2.Automatic spindle feed
3.Motorized lifting and lowering of head-stock
4.Headstock swivels±45°
5.Hardened and ground table surface.
Standard accessories:
Milling chuck collect
Middle sleeve
Inner-hexagon spanners
Dead head spanners
Machine vice
Mill arbor
Draw bar
Optional accessories:
DRO
58pcs Clamping kits
Universal dividing haed
Vertical&horizontal worktable
| SPECIFICATION | UNIT | XZ5150A | XZ5150 |
| Max.vertical milling dia. | mm | Φ32 | Φ32 |
| Max end mill width | mm | 125 | 125 |
| Max. drilling dia. | mm | Φ50 | Φ50 |
| Spindle taper | 7:24 ISO40 | 7:24 ISO40 | |
| Spindle travel | mm | 180 | 180 |
| Spindle speed range | r/min | 94-2256(16 steps) | 94-2256(16 steps) |
| Automatic Feed Series sleeve | mm/r | 0.1/0.15/0.3(3 steps) | 0.1/0.15/0.3(3 steps) |
| Distance spindle to table | mm | 100-580 | 100-600 |
| Distance spindle to column | mm | 400 | 400 |
| Swivel angle of headstock | ±45° | ±45° | |
| Up/down speeds of headstock | mm/min | 2000 | 2000 |
| Table size | mm | 1250×360 | 1220×360 |
| Table travel | mm | 600×360 | 600×360 |
| Table feeds range | mm/min | 22-555(8 steps)810(max.) | 18-555(8 steps)810(max.) |
|
T-slot of table (no./width/distance) |
mm | 3/18/80 | 3/14/95 |
| Main motor | kw | 1.5/2.4 | 1.5/2.4 |
| Motor of table power feed | w | 750 | 370 |
| Up/down motor of headstock | w | 550 | 550 |
| Coolant pump motor | w | 40 | 40 |
| N.W./G.W. | kg | 1900/2150 | 1760/2000 |
| Overall dimension | mm | 1800×1900×2300 | 1730×1730×2300 |
