FANUC 0i TD controller, Manual 4-jaw tube compound chuck, 4-station vertical electric toolpost,
Electric tailstock, Centralized automatic lubrication system, Cooling system, Working light,
Electrical cabinet with air conditioning, RS232 interface, Movable electronic
handwheel (MPG), Tri-color alarming light, General tools, Operation manuals (English edition).
|
Model |
QK1313 |
QK1319 |
QK1322 |
QK1327 |
QK1332 |
QK1343 |
QK1350 |
|
Bed width |
550mm |
550mm |
550mm |
750mm |
750mm |
750mm |
755mm |
|
Turning diameter |
630 mm |
630 mm |
630mm |
1000mm |
1000mm |
1000mm |
1200mm |
|
Max. diameter of |
126 mm |
190 mm |
219mm |
270mm |
320mm |
426mm |
520mm |
|
Turning length (Max.) |
1500 mm |
1500 mm |
1500mm |
1500mm |
1500mm |
1500mm |
1700mm |
|
Spindle bore |
130 mm |
200 mm |
225mm |
280mm |
330mm |
440mm |
520mm |
|
Spindle speed steps |
18 steps |
12 steps |
12 steps |
12 steps |
12 steps |
9 steps |
9steps |
|
Range of spindle speed |
12~640 |
24~300 |
24~300 |
16~380 |
16~380 |
5~200 |
6~205 |
|
Tool post |
Vertical 4-position |
Vertical 4-position |
Vertical 4-position |
Vertical 4-position |
Vertical 4-position |
Vertical 4-position |
Vertical 4-position |
|
Indexing time(s) |
3 |
3 |
3 |
2.4 |
2.4 |
2.4 |
2.4 |
|
Main motor (kw) |
7.5kw |
7.5kw |
7.5kw |
22kw |
22kw |
22kw |
37kw |
