Item

Unit

Spec.

Item

Unit

Spec.

General specification

kinds of module thread

kinds

45

Max. swing over bed

mm

1050

Range of module thread

mm

0.5-60

Max. length of workpiece

mm

3200

kinds of pitch thread

kinds

38

Max. swing over carriage

mm

640

range of pitch thread

DP

1/2~56

Max. diameter of bar for spindle bore

mm

121

Tool post

Max. turning length

mm

3000

Vertical distance of spindle center to tool mounting surface base

mm

48

Headstock

Size of tool rod

mm*mm

45*45

Bed width

mm

810

Swivel angle of tool post

± 90°

Spindle bore

mm

130

Max. travel of saddle

mm

3000

Spindle taper

Metric

140

Max. cross travel of lower slide

mm

650

Kinds of counterclockwise of spindle speed

kinds

21

Max. travel of upper slide

mm

300

Kinds of clockwise of spindle speed

Kinds

12

Tool post travel of per scale on dial of upper tool post and lower tool post

mm

0.05

Range of spindle speeds

Quick travel speed pf tool post

n(1) counterclockwise

r/min

3.15-315

Longitudinal

mm/min

3740

clockwise

r/min

3.5-278

Cross

mm/min

1870

n(2) counterclockwise

r/min

2-200

Top slide

mm/min

935

clockwise

r/min

2.24-178

Tailstock

Feeding box

Dia. of quill

mm

160

Kinds of longitudinal and cross feeding of tool post per revolution of spindle

kinds

56

Max. travel of quill

mm

300

Range of tool post feeding per revolution of spindle

Taper of quill

MT6

Longitudinal

mm/r

0.1-12

Main motor power

kw

22

Cross(one half of longitudinal)

mm/r

0.05-6

Overall dimension and weight

Upper slide(one quarter of longitudinal)

mm/r

0.025-3

Length

mm

6020

Kinds of metric thread

kinds

44

Width

mm

2150

Range of metric thread

mm

1-120

height

mm

1850

Kinds of inch thread

kinds

31

Net weight

kg

12500

Range of inch thread

TPI

28~1/4

Max. loading

kg

8000
