Model

GH-1340A

GH-1440A

General
Capacity

Max.Swing.over bed

mm

φ330mm（13〞）

φ356mm（14〞）

Max.Swing.over cross slide

mm

φ195（7-5/8〞）

φ210（8-5/8〞）

Max.Swing.over gap

mm

φ480（19〞）

φ506（20〞）

Bed width

mm

205(8〞)

Distance between centers

mm

1000(40〞/30〞)

Spindle

Taper of spindle bore

MT5

spindle bore

mm

Φ38（1-1/2〞）

Steps of spindle speeds

16steps

Range of spindle speeds

r/min

45-1800rpm

Spindle nose

D-4

Threading
&
Feeding

Metric thread range

mm

0.45~7.5(22kinds)

Inch screw thread range

TPI

4~112(40kinds)

Range of longitudinal feeds

mm

0.03-0.688(0.0011-0.0271〞in/rev)

Range of cross feeds

mm

0.015-0.220(0.0003〞-0.01〞in/rev)

Lead screw

Diameter of lead screw

mm

φ22(7/8〞)

Pitch thread of lead screw

mm

4(8T.P.I)

Tailstock

Travel of tailstock quill

mm

120(4-3/4〞)

Diameter of tailstock quill

mm

Φ45(1-25/32〞)

Taper of tailstock quill

MT3

Power

Main motor power

Kw

1.5/2.4(3HP)

Coolant pump motor power

Kw

0.04(0.055HP)

Overall dimensions of lathe(LxWxH)

mm

1880x720x1440

1880x740x1460

Packing size of lathe(LxWxH)

mm

1900x760x1460

1900x760x1480

Net Weight

Kg

875（1925ibs）

875（1925ibs）

Gross Weight

Kg

960(2112ibs)

1090(2112ibs)
