Wheel extractor
Coolant tank
Working lamp
Tools
Wheel dresser stand(not include diamond pen)
Standard grinding wheel
Leveling wedge
Leveling bolt
Standard magnetic chuck
Optional Accessories:
Wheel stand
Coolant tank with magnetic separator
Coolant with magnetic separator and paper filter
| Model | Unit | M7150A | M7150Ax1600 | M7150Ax2200 | M7163x1250 | M7163x1600 | M7163x2200 | |
| Worktable size(WxL) | Mm | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 | |
| Max matching dimension(W x L) | Mm | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 | |
|
Max distance between spindle center line and worktable surface |
Mm | 700 | ||||||
|
Longitudinal moving speed of worktable |
m/min | 3-27 | ||||||
| T-slot number x W | Mm | 3x22 | ||||||
|
Wheel head Cross moving |
Continuous feed speed |
m/min | 0.5-4.5 | |||||
|
Intermittent feed speed |
Mm/t | 3-30 | ||||||
| Hand wheel feed | Mm/gra | 0.01 | ||||||
|
Vertical Moving of wheel head |
Rapid speed | Mm/min | 400 | |||||
| Hand wheel feed | Mm/.gra | 0.005 | ||||||
|
Wheel Head motor |
Power | Kw | 7.5 | |||||
| Rotation speed | Rpm | 1440 | ||||||
| Total power | Kw | 12.25 | 13.75 | 15.75 | 13.75 | 15.75 | ||
|
Max loading capacity of worktable(with chuck) |
Kg | 700 | 1240 | 1410 | 1010 | 1290 | 1780 | |
| Chuck size(WxL) | Mm | 500x1000x1 | 500x800x2 | 500x1000x2 | 630x1250x1 | 630x800x2 | 630x1000x2 | |
| Wheel size(ODxWxID) | Mm | 400x40x203 | ||||||
| Machine dimension(LxWxH) | Cm | 311x190x242 | 514x190x242 | 674x190x242 | 399x220x242 | 514x220x242 | 674x220x242 | |
| Package dimension(LxWxH) | Cm | 320x228x252 | 520x228x252 | 680x228x252 | 410x228x252 | 520x228x252 | 680x228x252 | |
| Machine Weight | t | 5.78 | 7.32 | 8.78 | 6.86 | 7.85 | 9.65 | |
